Comprehensive Presentation Template

Demonstrating All Slide Types & Best Practices

Dr. Jane Smith

Department of Industrial Engineering

Date

2026-08-14

A comprehensive reference deck for layouts, media, code, and teaching patterns.

Introduction

Learning Objectives

By the end of this presentation, you will be able to:

Identify appropriate slide types for different content
Apply evidence-based design principles
Create accessible, professional presentations
Use Quarto’s cross-referencing and citation features

The Hook: Why This Matters

What if every presentation you gave was remembered and acted upon?

Core Slide Types

Title and Body

This is the most common slide type. It features:

A clear heading that states the slide’s main point
Supporting body text that elaborates
Optional visual elements (shown in later examples)

Design Tip

The slide title should be a complete thought, not just a topic label. “Heuristics Trade Speed for Optimality” is better than “Heuristics”.

Two-Column Layout

Text Column

Two-column layouts are effective for:

Comparing concepts side-by-side
Pairing text with supporting visuals
Creating visual balance

The 55/45 or 60/40 split gives text slightly more emphasis.

Figure 1: Decision flow diagram

TWO-COLUMN LAYOUT

Best Practice (Spatial Contiguity Principle): Related text and graphics should be placed near each other. This reduces the need to visually search, lowering cognitive load.

Usage:

:::: {.columns}
::: {.column width="55%"}
Left content
:::
::: {.column width="45%"}
Right content
:::
::::

When to Use: - Text + diagram/chart - Before/After comparisons - Concept + example

Three-Column Comparison

Constructive

Build solutions from scratch

Example: Nearest Neighbor

Improvement

Start with a solution and refine

Example: 2-opt, 3-opt

Metaheuristic

Escape local optima strategically

Example: SA, GA, Tabu

Big Number / KPI Slide

47%

Reduction in delivery costs using optimized routing

Compared to nearest-neighbor baseline across 50 test instances

Quote / Pull Quote

The goal is to turn data into information, and information into insight.

— Carly Fiorina, former HP CEO

This quote illustrates the value chain of analytics: raw data → processed information → actionable insight.

Emphasize Box (TED-Style Impact)

Every warehouse decision is a trade-off between space, time, and money.

EMPHASIZE BOX

Best Practice (Signaling Principle): Visual cues that highlight key information improve learning. The emphasize box creates a “quotable moment” that audiences remember.

TED Talk Technique: This is equivalent to the speaker pausing, stepping forward, and delivering a key line with emphasis.

Usage:

::: {.emphasize}
Your key message here with *italics* and **bold** for emphasis.
:::

When to Use: - Key takeaways - Memorable summaries - “Tweetable” insights

Visual Content

Figure with Caption

Figure 2: The optimization landscape showing local vs global optima. Heuristics help navigate this terrain efficiently.

See Figure 2 for the visualization. This demonstrates the challenge of escaping local optima.

Mermaid Diagram

Figure 3: Warehouse picking process flow

The process shown in Figure 3 illustrates the decision point between batch and single-order picking strategies.

Data Table (Tufte-style)

Table 1: Comparison of heuristic algorithms for routing problems

Algorithm	Time Complexity	Quality	Best For
Nearest Neighbor	\(O(n^2)\)	Fair	Quick baseline
Savings	\(O(n^2 \log n)\)	Good	VRP variants
2-opt	\(O(n^2)\) per iter	Very Good	TSP improvement
LKH	\(O(n^{2.2})\)	Excellent	Large TSP

As shown in Table 1, algorithm choice depends on problem size and quality requirements.

Code & Technical Content

Code Block with Highlighting

Listing 1: Nearest Neighbor heuristic implementation

import numpy as np

def nearest_neighbor(distance_matrix: np.ndarray) -> list[int]:
    """Construct a tour using the Nearest Neighbor heuristic."""
    n = len(distance_matrix)

    # Initialize: start at depot (node 0)
    visited = [False] * n
    tour = [0]
    visited[0] = True
    current = 0

    # Greedily visit nearest unvisited node
    for _ in range(n - 1):
        # Find nearest unvisited neighbor
        nearest = min(
            (j for j in range(n) if not visited[j]),
            key=lambda j: distance_matrix[current][j]
        )
        tour.append(nearest)
        visited[nearest] = True
        current = nearest

    tour.append(0)  # Return to depot
    return tour

Code with Output

# Create sample distance matrix
np.random.seed(42)
n = 5
coords = np.random.rand(n, 2) * 100

# Calculate distances
dist = np.zeros((n, n))
for i in range(n):
    for j in range(n):
        dist[i,j] = np.linalg.norm(
            coords[i] - coords[j]
        )

# Run algorithm
tour = nearest_neighbor(dist)
cost = sum(dist[tour[i], tour[i+1]]
           for i in range(len(tour)-1))

print(f"Tour: {tour}")
print(f"Cost: {cost:.2f}")

Output:

Tour: [0, 2, 4, 3, 1, 0]
Cost: 247.89

Interpretation

The algorithm visits nodes in order of proximity, producing a feasible but not necessarily optimal tour.

Mathematical Formulation

Consider the Traveling Salesman Problem (TSP):

\[ \min \sum_{i=1}^{n} \sum_{j=1}^{n} c_{ij} x_{ij} \tag{1}\]

Subject to:

\[ \sum_{j=1}^{n} x_{ij} = 1, \quad \forall i \in V \tag{2}\]

\[ \sum_{i=1}^{n} x_{ij} = 1, \quad \forall j \in V \tag{3}\]

Where \(x_{ij} \in \{0, 1\}\) indicates if edge \((i,j)\) is in the tour.

See Equation 1 for the objective function.

Teaching Slides

Exercise Box

Exercise: Manual 2-opt Calculation

Given the distance matrix below and initial tour A → B → C → D → A:

	A	B	C	D
A	0	10	15	20
B	10	0	35	25
C	15	35	0	30
D	20	25	30	0

Task: Calculate the cost change (Δ) if we reverse segment [B, C].

Time: 5 minutes

Solution (with Fragments)

Step 1: Identify edges to remove

Remove: (A,B) = 10 and (C,D) = 30
Total removed: 40

Step 2: Identify edges to add

Add: (A,C) = 15 and (B,D) = 25
Total added: 40

Step 3: Calculate Δ

\[\Delta = (15 + 25) - (10 + 30) = 40 - 40 = 0\]

Result

Δ = 0: This move does not improve the solution. Try reversing [B, C, D] instead!

Callout Variants

Note: Information

Used for supplementary information that’s helpful but not critical.

Tip: Best Practice

Used for recommendations and best practices.

Warning: Caution

Used for potential pitfalls or common mistakes.

Important: Critical

Used for essential information that must not be missed.

CALLOUT VARIANTS

Best Practice (Signaling Principle): Color-coded callouts create instant recognition. Learners know what type of information to expect [@mayer2009multimedia].

Usage Guidelines: - Note: Background info, tangents, FYI - Tip: Practical advice, shortcuts, best practices - Warning: Common errors, pitfalls, caveats - Important: Must-know information, critical points

Syntax:

::: {.callout-type}
## Optional Title
Content here.
:::

Workflow Slides

Break / Intermission

☕ Coffee Break

15:00

Please return by 10:45 AM

Q&A Slide

Questions?

Email: jane.smith@university.edu

Office Hours: Tuesday & Thursday, 14:00–16:00

Course Site: moodle.university.edu/course

Conclusion

Key Takeaways

Match slide type to content purpose — Use section dividers for transitions, emphasis boxes for impact moments
Apply multimedia learning principles — Combine words with visuals, segment complex information
Use Quarto features for professional output — Cross-references, citations, labeled elements
Include speaker notes — Document your design rationale for future reference

References

Thank You

Thank You!

Dr. Jane Smith

jane.smith@university.edu

Slides created with Quarto and reveal.js

Appendix: Additional Examples

Video Embedding

Before/After Comparison

BEFORE: Unoptimized

AFTER: Optimized

Full-Screen Image

Powerful Visual Impact

Full-bleed images create emotional connection

Highlighted Code (Advanced)

Click to expand full implementation

def two_opt(tour: list[int], dist: np.ndarray) -> list[int]:
    """Improve tour using 2-opt local search.

    Args:
        tour: Initial tour as list of node indices
        dist: Distance matrix

    Returns:
        Improved tour
    """
    improved = True
    best_tour = tour.copy()

    while improved:
        improved = False
        for i in range(1, len(best_tour) - 2):
            for j in range(i + 2, len(best_tour) - 1):
                # Calculate improvement
                delta = (
                    dist[best_tour[i-1], best_tour[j]] +
                    dist[best_tour[i], best_tour[j+1]] -
                    dist[best_tour[i-1], best_tour[i]] -
                    dist[best_tour[j], best_tour[j+1]]
                )

                if delta < -1e-10:
                    # Reverse segment
                    best_tour[i:j+1] = reversed(best_tour[i:j+1])
                    improved = True
                    break
            if improved:
                break

    return best_tour
